Country Comfort Water Heater
12V 4.3lpm 35psi Water Pressure Pump
12V 4.3lpm 35psi Water Pressure Pump
Couldn't load pickup availability
Country Comfort Water Heater 4.3lpm 35psi Water Pressure Pump comes standard in The Essential pack.
The 12v wiring harness is available to suit your 12v power. Just add to your order.
Great for pumping from your camper trailer, jerry can, 20lt bucket, caravan and boats. Pumps up to a 5m radius and 1m head.
All of our 12V pressure pumps are self-priming and low amp draw.
The 4.3L/min 35psi pressure pump may be used for general water transfer, sprayer pumps, small rain systems, or other industrial applications (Liquid with weak acid & alkaline properties is acceptable).
The pump will automatically turn off when pressure builds up, such as when you turn off the tap on the outlet hose & will automatically turn back on when you turn the tap back on.
The 12V wiring harness is available to suit your 12V power. Just add to your order.
**Note: We recommend using a filter with your pump to protect it from debris build-up, which can help prevent potential damage and ensure your warranty remains valid.
Special Functions
- Durable rubber feet for reduced vibration
- Long life, runs dry without damage, self-priming, built-in Check Valve, easy installation
- 2 Chamber Diaphragm
- (3/8”) 10mm Hose barb inlet/outlet
- Liquid: 60°C Max
- Self-priming: Within 1.5M
- Pressure PSI: 35 PSI
- Run Dry: Yes
- Motor: 12V Permanent Magnet, Intermittent Duty
- Protection: Thermal Overload, Automatic Restart
- Leads: 16 AWG Red + Black
Dimensions
170mm Length x 100mm Width
Materials
- Housing: PA66
- Check valves: EPDM
- Diaphragm: Santoprene
- Check valve spring: Stainless steel
- APPROVALS: CE & Rohs
Technical Data
- Model:YML-2202-1
- Volts: 12
- Flow (L/Min): 4.3
- Pressure (PSI): 35
- AmpDraw (A): 3.5
